• Dipasang24 Juni 2020
• Harga11.550
• KotaJAKARTA BARAT
• MerkTheodolite Digital H
• TipeTheodolite Digital H
• KondisiBaru

TOKO MARGA SETIA SURVEY
Berdagang alat- alat Kelautan, Alat Selam, Perahu Karet,Alat Keselamatan,
GPS Garmin, GPS Magellan, Alat Survey, Alat Ukur dan Aksesoris Alat Ukur.
Current Meter.Anemometer ,Anemometer Wireless,Weather station
Untuk keterangan, nego harga dan informasi produk lainnya, hubungi :
Name       : tatang survey
Alamat      : Jl .H.Kelik No.20 RT.03 / RW.08 Kelapa Dua Kebon Jeruk Jakarta Barat
Email        : tatangms409@gmail.com
Telp          : 082124100046

WhatsApp  :082124100046

Theodolite Digital HI TARGET DT-02
Hi-target DT-02 System Features:
• Laser and Collimation Axis – Coaxial
• Visible Laser Point
• Intelligent Calibration
• Absolute Encoding, Accuracy 2”
• Dual Side Large Back-lit LCD
• Laser Plummet
• Laser Visible Up to 200 Meters
Technical parameter DT-02
Angle Measurement Accuracy 2 ”
Reading system Absolute encoding
Minimum reading 1’ ’ / 5’ ’ / 10’ ’ / 20’ ’ ( Selectable)
Diameter of circle ( VHz) 79mm
Telescopic Image Erect
Magnification 30×
Clear Objective aperture 45mm
Angle of field of view 1° 202
Shortest stadia 2m
Stadia multiplying constant 100
Stadia additive constant 0
Resolving power 43
Laser Pointer ( DT-02L Only) Method Focusing
Wavelength/ Power 635nm/ 1mW
Laser class Class II
Laser range 200m( day time)
Spot size 5mm/ 100m
Coaxial 5mm/ 70m
Display LCD display type Dual side back-lit LCD
Data Interface Serial communication RS-232
Illumination Display yes
Reticle yes
Compensator Tilt sensor Liquid-electric vertical detection
Range of compensator ± 32
Accuracy 1 ”
Laser Plummet Image Erect
Magnification 3×
Angle of field of view 5°
Accuracy 1mm/ 1.5m
Level Sensitivity Accuracy of plate bubble 303/ 2mm
Accuracy of circular bubble 82/ 2mm
Power Supply Battery RechargeableNi-H battery
Continuous operating time 10h
Others Weight of theodolite 4.6kg
Dimensions 164× 154× 340mm
Water & dust protection IP54
Working environment temperature -20° C~ + 50° C
