• Dipasang7 Juli 2016
• Harga500.000
• KotaJakarta Selatan
• MerkPLANET
• TipePOE-164
• KondisiBaru

Hardware Specifications

Interface : Data  Input Port: 1 x RJ45 STP

 PoE (Data + Power) Output Port: 1 x RJ45 STP

 AC Input Power Socket: 1

LED Indicator : System: Power x 1 (Green)

 PoE Port: Active, PoE ready-in-use x 1 (Green)

Network Cable : 10BASE-T: 2-pair UTP Cat. 3, 4, 5, up to 100m (328ft)

 100BASE-TX: 2-pair UTP Cat. 3, 4, 5, up to 100m (328ft)

 EIA/TIA-568 100-ohm STP (100m)

Data Rate : 10/100Mbps

Dimensions

(W x D x H) : 115 x 62.5 x 31 mm

Weight : 182g

Unit Output Voltage : DC 53V, 0.6A

Power Requirements : 100-240V AC, 50/60Hz, 0.75A

Power Consumption : 30 watts (max.)

Number of Devices that

can be powered : 1

Operating Temperature : 0 ~ 50 degrees C

Storage Temperature : -10 ~ 70 degrees C

Operating Humidity : 5 ~ 95%, relative humidity, non-condensing

Storage Humidity : 5 ~ 95%, relative humidity, non-condensing

Power over Ethernet

PoE Standard :IEEE 802.3at Power over Ethernet Plus/PSE

PoE Power Output : DC 53V/30 watts

PoE Power Supply Type : Mid-span

Power Pin Assignment : 4/5(+), 7/8(-)

Standards Conformance

Standards Compliance : IEEE 802.3 10BASE-T Ethernet

 IEEE 802.3u 100BASE-TX Fast Ethernet

 IEEE 802.3at High Power over Ethernet Plus

 IEEE 802.3af Power over Ethernet

Regulatory Compliance : FCC Part 15 Class B, CE

** Garansi 1 tahun untuk kerusakan pabrik (kerusakan karena kelalaian user, force majeur,arus pendek & kena petir tidak garansi) **
